Edge bander

1.Introduction

The edge sealing link in the furniture production process is very important, especially with the advent of the "high-end customization" era. The quality of edge sealing directly affects the quality of the final product, so choose laser edge sealing with stable performance, high-quality edge sealing, and flexibility. Machinery is crucial for both haute couture companies and companies pursuing high-quality products. The laser edge banding machine itself has many advantages such as no pollution, strong penetration, non-destructive, no need for preheating, no noise, constant energy value, energy saving and efficiency, and maintenance-free. It is undoubtedly a seamless and glue-free edge sealing effect. Line, the best choice for flawless.

2.Parameters

Laser parameters

Optical Parameters
Project Output Power（w）	3000w	4000w
Power Instability	<3%
Power Adjustment Range/%	10~100
Center Wavelength（nm）	980
Fiber Output Head Type	QBH
Output Fiber Length	5m
Electrical Properties
Operating Voltage	Three-phase four-wire AC 380v±10%
Control Method	RS-232
Maximum Power Consumption（w）	8000	9000
Other Features
Dimensions/mm	834.5610249	830670260
Cooling Method	Water Cooling
Working Environment Temperature Range	-15-35℃

Laser Scanner Parameters

Product Parameters
Scan Range/mm	18-25（Continuously Adjustable)	35-50（Continuously Adjustable）
Dimensions/mm	10046315	12080320
Focal Length Range/mm	Standard Value 280
Working Environment Temperature Range	-15-35℃

Edge thickness

HS3000	HS4000
15-25mm	30-45mm

3.Advantages

(1) No pollution

(2) Strong food power

(3) Non-destructive

(4) No preheating required

(5) Noiseless

(6) Energy value is constant

(7) Energy saving and efficiency improvement

(8) Maintenance free

4.Precautions

(1) Check whether the red light indicator spot is abnormal before the equipment is used every day. If there are abnormal black spots, conduct a surface inspection of the laser exit window.

(2) The surface inspection of the laser exit window must be carried out when the equipment is powered off, and the routine inspection frequency is once a week. If contamination is found, replace the included lenses.

(3) Check whether the water level and temperature of the water cooler have reached the set temperature before equipment work every day. Preheating and precooling are required in winter and summer, usually 15 minutes.

(4) The cooling water of the water cooler needs to be deionized and purified water, and the cooling water containing impurities will damage the optical part. The standard water cooler setting water temperature is 25°.

(5) Laser equipment operators must be trained to operate as required. They must wear laser protective glasses during work and are prohibited from visually viewing laser beams and reflected and scattered beams.

(6) It is prohibited to insert any objects into the laser light path. Including metal, lenses, wood pieces, paper pieces, hands, etc.

(7) It is prohibited to disassemble and bend the optical fiber, and it is prohibited to hang objects on the optical fiber.

(8) For long-time shutdown, the output window needs to be protected. The cooling water needs to be drained.
